| Air flow at 1 speed - extractor by EN 61591 125 m3/h |
Air flow at 2 speed - extractor by EN 61591 157 m3/h |
Air flow at 3 speed - extractor by EN 61591 280 m3/h |
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 280 m3/h |
Air Flow at Minimum Speed in Normal Use 125 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 154.3 m3/h |
| Air Pressure at Best Efficiency Point P BEP 221 Pa |
Annual energy consumption 60.2 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 257 lux |
| Control panel on one side/two sides One side |
Country of Origin on Rating Label Made in EU |
Dimensions of grease filter 222.5 x 250 x 9 mm |
| Display color No |
Distance from light cover to wall 20 mm |
Distance to electric hob 450 mm |
| Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 95.5 W |
Fluid Dynamic Efficiency - FDE hood 9.9 |
| Fluid Dynamic Efficiency Class E |
Grease Filtering Efficiency - GFE hood 61.9 % |
Grease Filtering Efficiency Class E |
| Internal/external motor Internal |
Lighting Efficiency - LE hood 42.8 lux/W |
Lighting Efficiency Class A |
Lighting Efficiency Class A |
Maximum Possible Air Flow 280 m3/h |
Motor unit rated power 115 W |
Motor type/model K-28 030 00 HE (obud. MT) |
Net depth 350 mm |
Net height max 1330 mm |
Net height min 960 mm |
Net weight 10 kg |
Net width 600 mm |
Noise level at 1 speed - extractor by EN 60704-2-13 47 dB |
Noise level at 2 speed - extractor by EN 60704-2-13 52 dB |
Noise level at 3 speed - extractor by EN 60704-2-13 63 dB |
Nominal Power of the Lighting System - W L 6 W |
Number of motor units 1 |
Number units of main lighting 2 |
Air exhaust diameter 150 mm |
Type of plug or cable Euro plug |
Power cabel length 145 cm |
Power rating 121 W |
Power Supply Voltage 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 63 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 47 dB |
Noise level 63 dB |
Time Increase Factor - f 1.6 |
Type of main lighting LED |
