| Air flow at 1 speed - extractor by EN 61591 424 m3/h |
Air flow at 2 speed - extractor by EN 61591 545 m3/h |
Air flow at 3 speed - extractor by EN 61591 650 m3/h |
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 650 m3/h |
Air Flow at Minimum Speed in Normal Use 424 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 347.2 m3/h |
| Air Pressure at Best Efficiency Point P BEP 340 Pa |
Aastane energiatarbimine 67.8 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 78 lux |
| Container qty 40'HQ 435 |
Control panel on one side/two sides One side |
Country of Origin on Rating Label Made in PRC |
| Dimensions of grease filter 278 x 211 mm |
Display color Red |
Distance from light cover to wall 6 mm |
| Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 150.2 W |
| Sujuv dünaamiline tõhusus 21.8 |
Sujuv dünaamiline tõhusus C |
Grease Filtering Efficiency - GFE hood 82.6 % |
| Rasva väljafiltreerimise tõhusus C |
Internal/external motor Internal |
Main lighting colour temperature [K] 6500 |
Valgustus 28.9 lux/W |
Valgustõhususe klass A |
Valgustus A |
Maximum Possible Air Flow 650 m3/h |
Motor unit rated power 230 W |
Motor type/model E series |
Net depth 500 mm |
Net height max 930 mm |
Net height min 550 mm |
Puhaskaal 14 kg |
Net width 600 mm |
Müratase 57 dB |
Müratase 63 dB |
Müratase 68 dB |
Nominal Power of the Lighting System - W L 2.7 W |
Number of motor units 1 |
Number units of main lighting 2 |
Õhuväljalaske läbimõõt 150 mm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.46 W |
Toitejuhtme pikkus 120 cm |
Power rating 234 W |
Power Supply Voltage 230V |
Power unit of main lighting 2 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 68 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 57 dB |
Müratase 68 dB |
Time Increase Factor - f 1.2 |
Type of main lighting LED - other |
