| Frequency 50 |
Air flow at 1 speed - extractor by EN 61591 220 m3/h |
Air flow at 2 speed - extractor by EN 61591 290 m3/h |
| Air flow at 3 speed - extractor by EN 61591 366 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 366 m3/h |
Air Flow at Minimum Speed in Normal Use 220 m3/h |
| Air Flow Rate at Best Efficiency Point - Q BEP 210.2 m3/h |
Air Pressure at Best Efficiency Point P BEP 182.3 Pa |
Aastane energiatarbimine 51.8 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 335 lux |
Container qty 40'HQ 543 |
Control panel on one side/two sides One side |
| Dimensions of grease filter 338.8X227.8 |
Display color Red |
Distance from light cover to wall 38 mm |
| Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 83.6 W |
| Sujuv dünaamiline tõhusus 12.7 |
Sujuv dünaamiline tõhusus E |
Grease Filtering Efficiency - GFE hood 48 % |
| Rasva väljafiltreerimise tõhusus F |
Internal/external motor Internal |
Main lighting colour temperature [K] 3000 |
Valgustus 40.4 lux/W |
Valgustõhususe klass A |
Valgustus A |
Maximum Possible Air Flow 366 m3/h |
Motor unit rated power 120 W |
Motor type/model F series |
Net depth 378 mm |
Net height max 1138 mm |
Net height min 758 mm |
Puhaskaal 11.24 kg |
Net width 600 mm |
Müratase 58 dB |
Müratase 63 dB |
Müratase 65 dB |
Nominal Power of the Lighting System - W L 8.3 W |
Number of motor units 1 |
Number units of main lighting 2 |
Õhuväljalaske läbimõõt 120 mm |
Type of plug or cable Euro plug |
Power Consumption in Off Mode - Po 0.45 W |
Toitejuhtme pikkus 120 cm |
Power rating 128 W |
Power Supply Voltage 230V |
Power unit of main lighting 3.5 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 65 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 58 dB |
Müratase 65 dB |
Time Increase Factor - f 1.5 |
Type of main lighting LED GU10 |
