| Frequency 50 |
Air flow at 1 speed - extractor by EN 61591 211 m3/h |
Air flow at 2 speed - extractor by EN 61591 276 m3/h |
| Air flow at 3 speed - extractor by EN 61591 366 m3/h |
Air flow at 4 speed - extractor by EN 61591 622 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 622 m3/h |
| Air Flow at Minimum Speed in Normal Use 211 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 322.7 m3/h |
Air Pressure at Best Efficiency Point P BEP 405 Pa |
| Aastane energiatarbimine 65.7 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 371 lux |
Control panel on one side/two sides One side |
| Country of Origin on Rating Label Made in EU |
Dimensions of grease filter 222.5x250x9 |
Display color Red |
| Distance from light cover to wall 10 mm |
Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
| Electric Power Input at Best Efficiency Point - W BEP 147.7 W |
Sujuv dünaamiline tõhusus 24.6 |
Sujuv dünaamiline tõhusus B |
| Grease Filtering Efficiency - GFE hood 62.2 % |
Rasva väljafiltreerimise tõhusus E |
Internal/external motor Internal |
Valgustus 42.6 lux/W |
Valgustõhususe klass A |
Valgustus A |
Maximum Possible Air Flow 622 m3/h |
Motor unit rated power 260 W |
Motor type/model S-45 004 01 |
Net depth 375 mm |
Net height max 970 mm |
Net height min 780 mm |
Puhaskaal 9.72 kg |
Net width 600 mm |
Müratase 49 dB |
Müratase 53 dB |
Müratase 58 dB |
Müratase 67 dB |
Nominal Power of the Lighting System - W L 8.7 W |
Number of motor units 1 |
Number units of main lighting 2 |
Õhuväljalaske läbimõõt 150 mm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.25 W |
Toitejuhtme pikkus 170 cm |
Power rating 266 W |
Power Supply Voltage 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 67 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 49 dB |
Müratase 67 dB |
Time Increase Factor - f 1.1 |
Type of main lighting LED |
