| Frequency 50 |
Air flow at 1 speed - extractor by EN 61591 130 m3/h |
Air flow at 2 speed - extractor by EN 61591 170 m3/h |
| Air flow at 3 speed - extractor by EN 61591 315 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 315 m3/h |
Air Flow at Minimum Speed in Normal Use 130 m3/h |
| Air Flow Rate at Best Efficiency Point - Q BEP 175 m3/h |
Air Pressure at Best Efficiency Point P BEP 165 Pa |
Aastane energiatarbimine 64.2 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 271 lux |
Control panel on one side/two sides One side |
Country of Origin on Rating Label Made in EU |
| Dimensions of grease filter 250 x 300 x 9 mm |
Display color No |
Distance from light cover to wall 15 mm |
| Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 96.4 W |
| Sujuv dünaamiline tõhusus 8.3 |
Sujuv dünaamiline tõhusus E |
Grease Filtering Efficiency - GFE hood 64.7 % |
| Rasva väljafiltreerimise tõhusus E |
Internal/external motor Internal |
Valgustus 43 lux/W |
Valgustõhususe klass A |
Valgustus A |
Maximum Possible Air Flow 315 m3/h |
Motor unit rated power 115 W |
Motor type/model K-28 030 00 HE |
Net depth 450 mm |
Net height max 950 mm |
Net height min 680 mm |
Puhaskaal 13.36 kg |
Net width 600 mm |
Müratase 49 dB |
Müratase 52 dB |
Müratase 66 dB |
Nominal Power of the Lighting System - W L 6.3 W |
Number of motor units 1 |
Number units of main lighting 2 |
Õhuväljalaske läbimõõt 150 mm |
Type of plug or cable Euro plug |
Toitejuhtme pikkus 120 cm |
Power rating 121 W |
Power Supply Voltage 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 66 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 49 dB |
Müratase 66 dB |
Time Increase Factor - f 1.7 |
Type of main lighting LED |
